High efficiency: The packaging speed is extremely fast, with the capacity to package 1,600 to 2,400 bags per hour (for example, 25kg per bag).
Cost savings: By directly using roll film for online bag production, the cost of packaging materials is lower than that of pre-purchased finished bags. This can save tens of thousands of US dollars in a year.
The preferred choice for the petrochemical, chemical, fertilizer, plastic particle, and feed industries.
Device for piercing microholes in film bag tubes to release air from the bags
45° heat-sealing welding at the folded bottom corners and mouth corners of the bag
Probe-type air release device to reduce the volume of fluidized materials
Cleaning device for the edge of the packaging bag opening for dusty materials
Appropriate painting of equipment according to material requirements
The entire equipment is made of stainless steel
Chassis for mobile equipment (manual or motorized) to enable the equipment to use multiple material inlets (silos) and package materials with different characteristics
Device for reopening and cleaning the edge of the bag opening when packaging materials that interfere with heat-sealing welding
Probe-type device for releasing air between the material discharge and the sealing
Cleaning device for the edge of the packaging bag opening for dusty materials with a dust suction hood
Dust-proof bearing set on the bag-clamping device
Device for welding U-shaped bolts at the bag opening seal
Speed:
up to 41 bags per minute (1200-2500 per hour)*
Bulk materials:
granules, pellets
Packaging accuracy:
2‰
Bag width:
350-450mm
Bag longth:
550-1000mm
Bag types:
tubular film
Bag materials:
PE, PP, aluminum PP
Bag weight:
10 to 50 kg
Film roll:
Diameter:
1500mm
Internal core:
150 mm
Typical footprint:
LxWxH(4550x1660x2834mm)
Compressed air:
>0.6MPa
Gas consumption:
≤3m³ / minute
Power:
10Kw
Electrical requirement:
380 V / 3Ph / 60 Hz
Operating temperature:
5 °C to 40 °C
